Synergy 21 Square Wall Light 12W RGB+CCT Zigbee 3.0 IP66 *Milight/Miboxer* 24V
product pictures similar, may differ from the product description!
- stock: 0
- part no.: 235902
- vendor: Miboxer
- mnufacturer no.: WA5-09S-ZL
- EAN No.: 4038816138071
- weight: 1kg
- warranty: 60 months
- Do you have any questions concerning this product?
EU RoHS und REACH Erklärung
9W RGB+CCT LED Square Wall Light (Zigbee 3.0) DC24V
bull; Product follow zigbee 3.0 standard... more
Product information "Synergy 21 Square Wall Light 12W RGB+CCT Zigbee 3.0 IP66 *Milight/Miboxer* 24V"
9W RGB+CCT LED Square Wall Light (Zigbee 3.0) DC24V
bull; Product follow zigbee 3.0 standard protocol
bull; 16 Millions of colors to choose
bull; Brightness and color temperature adjustable
bull; Contrl distance: 100m (open area)
bull; IP66 waterproof
Product Parameters
| Product Name |
9W RGB+CCT LED Square Wall Light (Zigbee 3.0) DC24V |
|---|---|
| Model No. |
WA5-09S-ZL |
| Input Voltage |
DC24V |
| Power |
9W |
| PF | |
| CRI |
>80 |
| Color Temperature |
2700K~6500K |
| Luminous Flux |
720LM |
| Luminous Efficiency |
80LM/W |
| Beam Angle | |
| Communication Protocol |
Zigbee 3.0 |
| Control Distance |
100m (open area) |
| IP Rate |
IP66 |
| Working Temperature |
-20~45°C |
| Wireless Technology |
Zigbee 802.15.4 |
| Zigbee Wireless Frequency |
2.400-2.480GHz |
| Illumination Distance |
>8m |
Produktmerkmale:
| Abstrahlwinkel: | 360 |
| CRI: | >80 |
| Dimmbar: | ja |
| LED - Gehäusefarbe: | schwarz |
| LED - Gehäusematerial: | Aluminium |
| Lichtfarbe: | RGB-CCT |
| Lichtfarbe in Kelvin: | 2700~6500 |
| Lumen: | 940 |
| Schutzklasse: | IP66 |
| Volt: | 24 |
| Watt: | 9 |
Informationen zur Energieeffizienz
| Energieeffizienz Klasse G | |
|---|---|
| kwh/1000h: | 9,00 |
| Lumen: | 940 |
| Watt: | 9,0 |
| Nennlebensdauer: | 35000 Std. |
| Schaltzyklen: | 50000 |
| Opt. Umgebungstemperatur: | 25 °C |
| EEK Label | Download |
