Siglent SDG6022X / 2-channel, 200MHz signal generator

The SDG6022X from SIGLENT is a two channel pulse / arbitrary waveform generator with 200 MHz bandwidth, a maximum sampling rate of 2.4 GSa/s and a vertical resolution of 16 bit. It also includes proprietary TrueArb & EasyPulse technology, which helps eliminate the oscillations of traditional DDS generators in the generation of arbitrary, square-wave and pulse waveforms. In addition, the SDG6022X is a multifunction device that can generate noise, IQ signals and PRBS patterns. These features enable the SDG6022X to deliver a variety of high fidelity and low jitter signals to meet the growing demands of complex and intensive applications.

Main features

• 2 channels
• 200 MHz Maximum bandwidth
• 20 Vpp maximum output amplitude
• High fidelity output with 80 dB dynamic range
• Powerful sampling system with 2.4 GSa/s sampling rate and 16 bit vertical resolution
• Harmonic function
• Waveform Combination function
• Channel coupling, copying and tracking functions
• 196 built-in arbitrary waveforms
• High-precision frequency selector
• Standard interfaces: USB Host, USB Device (USBTMC), LAN(VXI-11, Socket, Telnet)GPIB
• 4.3" Touch Screen Display
