Mean Well power supply - CC Driver 700mA ~36V 0-10V dimm IP67
product pictures similar, may differ from the product description!
- stock: 0
- part no.: 113860
- vendor: Meanwell
- mnufacturer no.: LPF-25D-36
- EAN No.: 4711287458755
- weight: 0.35kg
- Do you have any questions concerning this product?
Downloads
data sheet DE
EU RoHS und REACH Erklärung
LPF-25-36
IP67
Dimmable: 0-10V see data sheet
Input: 90-305VAC
Output: 0.7A, 19.8-36V DC,... more
Product information "Mean Well power supply - CC Driver 700mA ~36V 0-10V dimm IP67"
LPF-25-36
IP67
Dimmable: 0-10V see data sheet
Input: 90-305VAC
Output: 0.7A, 19.8-36V DC, 25.2 Watt constant current
Operating temperature: -40°C to +70°C, see data sheet
LxWxH 148x40x32mm
Protection markings: see data sheet
Open cable ends
Produktmerkmale:
| Ampere: | 0.70 |
| Betriebstemperatur: | -40 bis +70 |
| CC oder CV: | CC |
| Dimmbar: | ja |
| Grösse: | 148*40*32 |
| Schutzklasse: | IP67 |
| Volt: | 8-36 |
| Watt: | 25.20 |
