Synergy 21 LED Flex Strip 60 RGB DC24V + RGB-W ein Chip nw IP68
product pictures similar, may differ from the product description!
- stock: 0
- part no.: 141094
- vendor: Synergy 21 LED
- mnufacturer no.: S21-LED-F00161
- EAN No.: 4038816066541
- weight: 0.55kg
- warranty: 24 months
- Do you have any questions concerning this product?
Downloads
data sheet DE
data sheet EN
EU RoHS und REACH Erklärung
RGB-W Flex-Stripe, 5 metres, RGB and neutral white on one chip
Neutral white: 4250K
IP68 with... more
Product information "Synergy 21 LED Flex Strip 60 RGB DC24V + RGB-W ein Chip nw IP68"
RGB-W Flex-Stripe, 5 metres, RGB and neutral white on one chip
Neutral white: 4250K
IP68 with silicone tube (filled tube)
DC 24V, 96W, 24Watt nw, 72Watt RGB, 4A max.
Brightness: 1700lm
300 PCS 5050 SMD LED
common positive pole
L*W*H: 5000*15*5.5 mm
can be shortened: all 6 LEDs can be shortened (10 cm)
Adhesive tape for mounting aid on the back
Control via Synergy 21 Controller 3653 or
RGBW EOS controller (radio, DMX, etc.)
Please note that LED strips must also be cooled.
Ensure that the LED strip does not exceed an operating temperature of 40°C, otherwise the service life cannot be guaranteed.
IP68 LED strips may have slight colour variations due to the silicone protective coating
Energy efficiency class: A (for white)
kWh/1000h: 26.4
Produktmerkmale:
| Abstrahlwinkel: | 120 |
| Ampere: | 4 |
| CC oder CV: | CV |
| Dimmbar: | abhängig vom Netzteil |
| LED Strip Klebeband: | ja |
| LED Strip Breite: | 15 |
| LED Strip Höhe: | 5,5 |
| LED Strip Länge: | 5000 |
| LED Strip kürzbar: | 100 |
| Lichtfarbe: | RGB-W |
| Schutzklasse: | IP68 |
| Volt: | 24 |
| Watt: | 96 |
Informationen zur Energieeffizienz
| Energieeffizienz Klasse G | |
|---|---|
| kwh/1000h: | 105,6 |
| Lumen: | 1700 |
| Watt: | 96,0 |
| Nennlebensdauer: | 35000 Std. |
| Schaltzyklen: | 50000 |
| Opt. Umgebungstemperatur: | 25 °C |
| EEK Label | Download |
