Rock Pi 4 Model A 4GB (ohne WLAN/Bluetooth/PoE)
- stock: 0
- part no.: 177010
- vendor: ALLNET
- mnufacturer no.: Rock44GBA
- EAN No.: 4038816177018
- weight: 0.15kg
- warranty: 12 months
- Do you have any questions concerning this product?
Downloads
declaration of conformity data sheet DE data sheet ES EU RoHS und REACH ErklärungRock Pi 4 Model A 4GB (without WLAN/Bluetooth and PoE)
Rockchip RK3399< Processor64bit6-core
Dual Cortex-A72 with 1.8Ghz; Quad Cortex-A53 with 1.4Ghz
GPU
Mali T860MP4 GPU, supports OpenGL ES 1.1 /2.0 /3.0 /3.1 /3.2, Vulkan 1.0, Open CL 1.1 1.2, DX11.
Memory LPDDR4
4GB 64bit dual channel LPDDR4@3200Mb/s, 4GB
Storage eMMCModule
Optional industrial-grade high-performance eMMC module, 8G/16G/32G/64G/128G available
Micro SD card
uSD Slot supports up to 128G uSD cards
M.2 SSD
M.2 connector supports up to 2T M.2 NVME SSD
Display HDMI
HDMI 2.0 up to 4k@60
Periphery
MIPI DSI 2 lanes via FPC Connector
HDMI and MIPI DSI works simultaneously, supports mirror mode and extend mode.
Audio 3.5mm jack with microphone support
HD codec, supports up to 24-bit/96kHz audio
MIPI CSI camera
MIPI CSI 2 Lanes via FPC Connector, supports up to 800MP cameras
USB 3.0 OTG x1
Hardware Switch für host/device switch, top
USB 3.0 HOST x1
dedicated USB3.0 channel, bottom
USB 2.0 HOST x2
LAN
GbE LAN
IO 40-pinExtension header :
- 1 x UART
- 2 x SPI bus
- 2 x I2C bus
- 1 x PCM/I2S
- 1 x SPDIF
- 1 x PWM
- 1 x ADC
- 6 x GPIO
- 2 x 5V DC power in
- 2 x 3.3V power pin
Other
RTC battery connection for time backup (optional)
Power USB PD
Support USB Type C PD 2.0, 9V/2A, 12V/2A, 15V/2A, 20V/2A
Power Supply Qualcomm® Quick Charge™
Support QC3.0/2.0 adapter, 9V/2A, 12V/1.5A
Maße 85mm x 54mm
