Product information "Yeastar GSM-Gateway TG400 4x Kanal"

Highlights

Yeastar TG series connects GSM/3G/4G-networks directly to VoIP networks and enables bi-directional communication: GSM/3G/4G with VoIP and VoIP with GSM/3G/4G. The TG series is the best available solution to interconnect IP-based PBXs and provides a softswitch connection to a GSM/3G4G network. In addition, it is the best fallback solution when the fixed line fails.

  • Connect PBX systems to GSM or 3G WCDMA or 4G LTE networks
  • Send and receive SMS messages via web interface, supports bulk SMS
  • Save significant phone costs with mobile-to-mobile calls and SIP trunks
  • In the web-based management, everything can be set up effortlessly
  • Cost-effective backup when landline fails
  • Easy to integrate: high compatibility with established IPPBX and softswitch

Technical Specification

Models* TG100 TG200 TG400 TG800 TG1600
Number of Ports 1 2 4 8 16
GSM Frequency** 850/900/1800/1900 MHz
WCDMA Frequency** 850/1900 MHz, 850/2100 MHz, 900/2100 MHz
4G Data –
4G LTE Band** Don’t support 4G LTE Depending on the module type. Check the supported band and operators. Don’t support 4G LTE
Protocol SIP, IAX2
Antenna Splitter (4 in 1) – Support
Transport UDP, TCP, TLS, SRTP
Voice Codec G.711 (alaw/ulaw), G.722, G.726, G.729A, GSM, ADPCM, Speex
DTMF Mode RFC2833, SIP Info, In-band
Echo Cancellation ITU-T G.168 LEC
Calling Type Termination (VoIP to GSM/WCDMA), Origination (GSM/WCDMA to VoIP)
Network Protocol FTP, TFTP, HTTP, SSH
LAN 1 10/100 Mbps Ethernet Interface 2 10/100 Mbps Ethernet Interfaces
NAT Traversal Static NAT, STUN
Network DHCP, DDNS, Firewall, OpenVPN, Static IP, QoS, Static Route, VLAN
Operation Range 0°C to 40°C, 32°F to 104°F
Power Supply DC 12V, 1A AC 100-240V
Storage Range -20°C to 65°C, -4°F to 149°F
Dimensions (L × W × H) (mm) 110 x 70 x 24 213 x 160 x 44 340 x 210 x 44 440 x 250 x 44
Humidity 10-90% non-condensing

*You could order either GSM or 3G or 4G channel. TG100 and TG1600 do not support 4G LTE.
**Click here to check the frequency/band and cellular operators supported by TG GSM VoIP Gateway.
