Synergy 21 LED Flex Strip 120 DW (CCT) DC24V 36W per Colour IP20
- stock: 0
- part no.: 85039
- vendor: Synergy 21 LED
- mnufacturer no.: S21-LED-B00057
- EAN No.: 4038816997173
- weight: 0.15kg
- warranty: 24 months
- Do you have any questions concerning this product?
Downloads
data sheet DE
data sheet EN
data sheet ES
EU RoHS und REACH Erklärung
Colour selection between 3000-7000K possible with controller
ww: 3000K ±250, cw: 6500K ±250
5 metres, (5000*11*3mm)
24 Volt, common positive pole, 72 Watt total, 14.4W/M
6000Lm
600 high power 3528SMD LED
DC24V, 36W per colour, non-waterproof
Shortenable all 12 LED
Adhesive tape for mounting aid on the back
Strip can be shortened at marking points with sharp scissors.
!Attention! Strip must first be checked for functionality.
Only split the strip when no current is present.
Energy efficiency class: A
kWh/1000h: 72
Please note that LED strips also need to be cooled.
Make sure that the LED strip does not exceed an operating temperature of 40°C, otherwise the service life cannot be guaranteed.
Produktmerkmale:
| Abstrahlwinkel: | 120 |
| Ampere: | 4 |
| CC oder CV: | CV |
| CRI: | >80 |
| Dimmbar: | abhängig vom Netzteil |
| LED Strip Klebeband: | ja |
| LED Strip Breite: | 11 |
| LED Strip Chip Anzahl: | 120 |
| LED Strip Chip Typ: | 2835 |
| LED Strip Höhe: | 3 |
| LED Strip Länge: | 5000 |
| LED Strip kürzbar: | 100 |
| Lichtfabe in Kelvin: | 3000-7000 |
| Lichtfarbe: | dual weiß, CCT |
| Lichtfarbe Name: | dual weiß, CCT |
| Lichtfarbe in Kelvin: | 3000-7000 |
| Lumen: | 6000 |
| Länge: | 5 |
| Schutzklasse: | IP20 |
| Volt: | 24 |
| Watt: | 96 |
| Energieeffizienz Klasse G | |
|---|---|
| kwh/1000h: | 96.00 |
| Lumen: | 6000.00 |
| Watt: | 96.00 |
| Nennlebensdauer: | 35000.00 Std. |
| Schaltzyklen: | 50000.00 |
| Opt. Umgebungstemperatur: | 25.00 °C |
| EEK Label | Download |
