ALLNET Ersatznetzteil/Spannungswandler 5V/3A IN: 9~36VDC -> OUT: 5V DC/DC-Wandler Mean Well Hutschiene
product pictures similar, may differ from the product description!
net price plus shipping costs
This product is not available at the moment. Delivery time upon request.
- stock: 0
- part no.: 195459
- vendor: Meanwell
- mnufacturer no.: DDR-15G-5
- EAN No.: 4711287422916
- weight: 0.5kg
- warranty: 24 months
- Do you have any questions concerning this product?
Downloads
data sheet DE
EU RoHS und REACH Erklärung
Product details
Width of only 17.5 mm (1SU)
Especially large 4:1 input range... more
Product information "ALLNET Ersatznetzteil/Spannungswandler 5V/3A IN: 9~36VDC -> OUT: 5V DC/DC-Wandler Mean Well Hutschiene"
Product details
- Width of only 17.5 mm (1SU)
- Especially large 4:1 input range
- Large operating temperature range from –40 to +85 °C
- No minimum load required
- Adjustable DC voltage output (+/- 10 %)
- Cooling through free air convection
- Can be installed on DIN rail TS-35/7.5 or 15, reverse polarity/overvoltage protection at the input
- 4 kV DC I/O insulation (reinforced insulation)
- 3 years warranty
- Application
- Industrial control system
- Factory automation
- electromechanical
- wireless network
- Telecommunication or data communication system
- DC/DC ultra-flat industrial DIN rail converter, input 9–36 V DC, single output 5 V DC at 3 A
Technical data
| Property | Value |
| Input voltage | 9 → 36V dc |
| Output voltage | 5V dc |
| Output current | 3A |
| Nominal power | 15W |
| Number of outputs | 1 |
| Height | 90mm |
| Width | 17.5mm |
| Load levelling | ±1% |
| Temperature max | +85°C |
| Mounting type | DIN rail mounting |
| Depth | 54.5mm |
| Temperature min. | -40°C |
| Buzz and noise voltage | 50mV ss |
| Series | DDR-15 |
| Output voltage setting range | 4.5 → 5.5V |
| Operating time | 907kh |
Produktmerkmale:
| Ampere: | 3 |
| Betriebstemperatur: | -40 bis +85 |
| CC oder CV: | CV |
| Dimmbar: | Nein |
| Grösse: | 17,5*90*54,5 |
| Schutzklasse: | IP20 |
| Volt: | 5 |
| Watt: | 15 |
