Ubiquiti UniFi Access Door Closer • UACC-DoorCloser

product pictures similar, may differ from the product description!

This product is not available at the moment. Delivery time upon request.

A mechanical door closer that ensures controlled closing for safety and convenience.... more

Product information "Ubiquiti UniFi Access Door Closer • UACC-DoorCloser"

A mechanical door closer that ensures controlled closing for safety and convenience.

Highlights:

Mechanical
Maße	Lock body: 256.5 x 60 x 48 mm (12.9 x 3.5 x 2.1 inches)
Weight	3.3 kg
Housing material	Lock body: aluminium alloy, carbon steel, hot-rolled steel Decorative cover: cold-rolled steel
Max. Door opening angle	180°
Hardware
Power size	EN2-6
Scope of application	Standard door installation on the hinge side. Fanlight installation on the hinge side. (This option is not covered by the certificate.) Parallel bracket mounting on the hinge side. (Sizes 3-5 only.)
Standard/skylight mounting (door width/weight)	Force size 2: 850 mm / 40 kg Force size 3: 950 mm / 60 kg Force size 4: 1100 mm / 80 kg Force size 5: 1250 mm / 100 kg Force size 6: 1400 mm / 120 kg
Parallel bracket mounting (door width / weight)	Force size 3: 950 mm / 60 kg Force size 4: 1100 mm / 80 kg Force size 5: 1250 mm / 100 kg
Certifications	CE, EN 1154, EN 1634, AS 1530.4
