ALLNET Wireless AP WIFI6 • AX1200 • 2x2 • Outdoor • 1x GbE passive PoE 24VDC • IP55 • Bridge/AP/WDS • ALL-WB100AXF-1200

ALLNET Wireless AP WIFI6 • AX1200 • 2x2 • Outdoor • 1x GbE passive PoE 24VDC • IP55 • Bridge/AP/WDS • ALL-WB100AXF-1200
ALLNET Wireless AP WIFI6 • AX1200 • 2x2 • Outdoor • 1x GbE passive PoE 24VDC • IP55 • Bridge/AP/WDS • ALL-WB100AXF-1200
ALLNET Wireless AP WIFI6 • AX1200 • 2x2 • Outdoor • 1x GbE passive PoE 24VDC • IP55 • Bridge/AP/WDS • ALL-WB100AXF-1200
ALLNET Wireless AP WIFI6 • AX1200 • 2x2 • Outdoor • 1x GbE passive PoE 24VDC • IP55 • Bridge/AP/WDS • ALL-WB100AXF-1200
ALLNET Wireless AP WIFI6 • AX1200 • 2x2 • Outdoor • 1x GbE passive PoE 24VDC • IP55 • Bridge/AP/WDS • ALL-WB100AXF-1200
ALLNET Wireless AP WIFI6 • AX1200 • 2x2 • Outdoor • 1x GbE passive PoE 24VDC • IP55 • Bridge/AP/WDS • ALL-WB100AXF-1200
product pictures similar, may differ from the product description!

net price plus shipping costs

Ready to ship today,
Delivery time appr. 1-3 workdays

ALLNET Wireless AP WIFI6 • AX1200 • 2x2 • Outdoor • 1x GbE passive PoE 24VDC • IP55 •... more
Product information "ALLNET Wireless AP WIFI6 • AX1200 • 2x2 • Outdoor • 1x GbE passive PoE 24VDC • IP55 • Bridge/AP/WDS • ALL-WB100AXF-1200"

ALLNET Wireless AP WIFI6 • AX1200 • 2x2 • Outdoor • 1x GbE passive PoE 24VDC • IP55 • Bridge/AP/WDS • ALL-WB100AXF-1200

Highlights:

  • Wi-Fi 6 technology for powerful and efficient outdoor Wi-Fi
  • Beamforming optimizes antenna signal, reception, and reliability for clients
  • 2x2 directional antennas to support up to 1200 Mbps in the 5 GHz range
  • High transmit power of 26 dBm extends Wi-Fi to the yard or from building to building
  • Integrated directional antenna with high gain (16 dBi) extends wireless networks up to 5 miles (point-to-point)
  • IP55-certified weatherproof and dustproof enclosure
  • Flexible operating modes: access point, station, WDS access point, WDS station, repeater
  • GE PoE port supports flexible power options

The ALLNET Wireless Bridge WiFi6 2x2 5GHz IP55 Outdoor Long Range CPE provides reliable and efficient outdoor Wi-Fi connectivity with Wi-Fi 6 technology and beamforming optimization. It features a high transmit power of 26 dBm and an integrated high gain directional antenna of 16 dBi for extended Wi-Fi range of up to 5 miles (point-to-point). It is also weatherproof and offers flexible operating modes with easy installation over 100 meters.

Technical Details:

Model Name

ALL-WB100AXF-1200

Chipset

Main Control Unit

IPQ5018

Flash & Memory

8MB NOR (layout reserved)

128MB NAND

512MB DDR3 RAM

Switch/PHY

QCA8337 (1GbE)

PD

YES


Operating Frequency
Single band 5 GHz

Operation Mode
AP/STA/WDS AP/WDS STA/ Repeater

Frequency Radio
5 GHz: 5150 MHz ~ 5250 MHz, 5250 MHz ~ 5350 MHz, 5470 MHz ~ 5725 MHz, 5725 MHz ~ 5850 MHz

Radio Chains
2 x 2:2

SU-MIMO Capability
Two (2) spatial stream Single User (SU) MIMO for up to 1,200 Mbps wireless data rate with VHT80 to a 2×2 wireless device under the 5GHz radio.

MU-MIMO Capability
Two (2) spatial streams Multiple (MU)-MIMO up to 1,200 Mbps wireless data rate for transmitting to two (2) streams MU-MIMO 11ax capable wireless client devices under 5GHz simultaneously.

Supported Data Rates

802.11ax: 5 GHz: 18 to 1200 (MCS0 to MSC11, NSS = 1 to 2) 802.11b: 1, 2, 5.5, 11 802.11a/g: 6, 9, 12, 18, 36, 48, 54 802.11n: 6.5 to 300 Mbps (MCS0 to MCS15) 802.11ac: 6.5 to 867 Mbps (MCS0 to MCS9, NSS = 1 to 2)

Supported Radio Technologies
802.11ax: 802.11ax: Orthogonal Frequency Division Multiple Access(OFDMA) 802.11a/g/n/ac: Orthogonal Frequency Division Multiple (OFDM) 802.11b: Direct-sequence spread-spectrum (DSSS)

Channelization
802.11ax supports high efficiency throughput (HE) —HE 20/40/80 MHz 802.11ac supports very high throughput (VHT) —VHT 20/40/80 MHz 802.11n supports high throughput (HT) —HT 20/40 MHz 802.11n supports
high throughput under the 2.4GHz radio –HT40 MHz (256-QAM) 802.11n/ac/ax packet aggregation: A-MPDU, A-SPDU

Supported Modulation
802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM 802.11b: BPSK, QPSK, CCKA

Max. Concurrent User
128 per radio

RF Power Setting

Transmit Power (5GHz)

Conductive 22dBm per-chain @MCS0 20Mhz

Interfaces

Ethernet

1x 1GbE RJ45 54VDC Proprietary PoE INPUT
1x 1GbE RJ45 LAN Out

LED Indicator

4x single-color LED, 3x tri-color LED for signal

Reset Button

1x

Power Spec

Power Source

48V Proprietary PoE (EPA5006GR)


Max. Power Consumption
PoE: Max. 13W

Antenna

Antenna Specification

Internal Patch Array

1x single-band @5Ghz, 14dBi (Port1: 40°x20°;Port2: 40°x20°) 22dBm TX Power max.

Antenna Beamwidth: Azimuth:40°, Elevation:20°

Environmental

Rain & Dust ingression protection

IP55

Operating Temperature

-20°C ~ 60°C


Storage Temperature & Humidity
-40ºC ~ 80ºC
Storage: 90% or less

Humidity

Up to 95% RH, non-condensing

Mounting Options


Dimension
260*84*55mm

Wall Mount

YES

Pole Mount

YES

Certification

Marks FCC
CE
