Fanvil FH-S01, SIP Ceiling Speaker / SIP
- stock: 0
- part no.: 214007
- vendor: Fanvil
- mnufacturer no.: FH-S01
- EAN No.: 6937295603651
- weight: 2.74kg
- warranty: 24 months
- Do you have any questions concerning this product?
Downloads


FH-S01 is a SIP ceiling speaker featuring paging, multicasting, broadcasting and talkback functionalities. It supports up to 10 multicast zones with prioritization. It delivers high-intelligibility performance with G.722&Opus codecs. Adopted standard SIP 2.0(RFC3261) and related RFC protocols, it has strong compatibility and scalability.
size: 238.5mm*238.5,,*148.3mm
2 SIP Lines
PoE Support.
Technical Details
Model |
FH-S01 SIP Ceiling Speaker |
Installation | Ceiling-mounted |
Microphone | YES |
Speaker power | 20W/DC24V |
Frequency response | 100-20KHz |
Sensitivity | 89dB±3dB 1M/1W |
Audio filesstorage | 27MB |
Support protocol | SIP |
Maximum SPL | 96 dB |
Short circuit input | 1 |
Short circuit output | 1 |
Audio line in/output | × |
Power supply | DC 12V~24V/2A |
Protection Level | × |
Working temperature | -20°C~ 50°C |
Weight | 1.92kg |
Dimension(w×h×d) | 238.5×238.5× 148.3mm |
