Ubiquiti Switch full managed Layer2 8 Port Â• 4x 2,5 GbE Â• PoE Budget 160 Watt Â• 4x 27V Passive-PoE Â• 4x SFP+ Â• Desktop Â• Lüfterlos Â• UISP Â• UISP-S-Plus

Preview: Ubiquiti Switch full managed Layer2 8 Port Â• 4x 2,5 GbE Â• PoE Budget 160 Watt Â• 4x 27V Passive-PoE Â• 4x SFP+ Â• Desktop Â• Lüfterlos Â• UISP Â• UISP-S-Plus

product pictures similar, may differ from the product description!

net price plus shipping costs

This product is not available at the moment. Delivery time upon request.

Call us Mail us

EU RoHS und REACH Erklärung

stock: 0
part no.: 228617
vendor: Ubiquiti
mnufacturer no.: UISP-S-Plus
EAN No.: 8100846920288
weight: 1.75kg
warranty: 12 months
Do you have any questions concerning this product?

2.5-GbE PoE switch for ISP applications. (4) 2.5 GbE RJ45 ports with 27 V... more

Close menu

Product information "Ubiquiti Switch full managed Layer2 8 Port Â• 4x 2,5 GbE Â• PoE Budget 160 Watt Â• 4x 27V Passive-PoE Â• 4x SFP+ Â• Desktop Â• Lüfterlos Â• UISP Â• UISP-S-Plus"

2.5-GbE PoE switch for ISP applications.

(4) 2.5 GbE RJ45 ports with 27 V passive PoE output

(4) 10G SFP+ ports

160 W (27 V) total PoE availability*, 20 W/port (2-pair) / 40 W/port (4-pair)

Port isolation, speed limiting and DHCP snooping functionality

(1) Power TransPort™-input for DC redundancy

Desk, wall, 1U rack and external mounting**

Standalone management via local web interface and UISP application integration

_{*When powered via the supplied AC/DC adapter.}

_{**When included in the UISP Box Plus (sold separately).}

Mechanical
Maße	210.4 x 170.2 x 43.7 mm (8.3 x 6.7 x 1.7 inches)
Weight	1.75 kg
Walking materials	SGCC steel, polycarbonate/acrylonitrile-butadiene-styrene
Hardware
Processor	Dual-core ARM®v8 Cortex®-A55 with 1.4 GHz
Reminder	1 GB DDR4
Integrated flash memory	256 MB NAND
Network interface	(4) 1/2.5 GbE RJ45 LAN ports (4) 1/10G SFP+ ports
Management interface	Ethernet In-Band Bluetooth
Total non-blocking throughput	50 Gbit/s
Switching power	100 Gbit/s
Forwarding tariff	74.4 Mpps
Performance method	(1) External AC/DC power supply (1) Power TransPort DC input 27 V DC, 7.04 A
Power supply	27 V DC, 7.04 A power supply unit (included in the scope of delivery)
Supported voltage range	24–28 V direct current
Max. Power consumption	25 W (without PoE output.)
ESD/EMP protection	Air: ± 15 kV, Contact: ± 8 kV
Operating ambient temperature	-10 to 50 °C (14 to 122 °F)
Humidity during operation	5 to 95 % non-condensing
Certifications	CE, FCC, IC
PoE
PoE interface	(4) 27 V passive PoE: 2-pair (pins 4, 5+/7, 8-) or 4-pair (pins 1, 2, 4, 5+/3, 6, 7, 8-); ports 1 to 4
Totally available PoE	160 W (with supplied power supply unit.)
Max. passive PoE power per port	2-pair mode: 20 W/27 V DC 4-pair mode: 40 W/27 V DC
Passive PoE voltage range	27 V direct current
LEDs
System	Status
RJ45 data ports	PoE Speed/Connection/Activity
SFP+ data ports	Link/Activity
Software
Administrative application	UISP
