Ubiquiti Switch smart managed Layer2 9 Port • 8x 2,5 GbE • 1x 10 GbE PoE at In • Desktop • Lüfterlos • UniFi • USW-Flex-2.5G-8
product pictures similar, may differ from the product description!
net price plus shipping costs
This product is not available at the moment. Delivery time upon request.
- stock: 0
- part no.: 239767
- vendor: Ubiquiti
- mnufacturer no.: USW-Flex-2.5G-8
- weight: 0.42kg
- warranty: 12 months
- Do you have any questions concerning this product?
EU RoHS und REACH Erklärung
Flexible 8-port 2.5 GbE switch with a 10 GbE RJ45/SFP+ combination uplink port that can be... more
Product information "Ubiquiti Switch smart managed Layer2 9 Port • 8x 2,5 GbE • 1x 10 GbE PoE at In • Desktop • Lüfterlos • UniFi • USW-Flex-2.5G-8"
Flexible 8-port 2.5 GbE switch with a 10 GbE RJ45/SFP+ combination uplink port that can be supplied with power using a USB-C or PoE+ adapter.
Highlights:
- (8) 2.5 GbE ports
- (1) 10 GbE PoE+ input port for power / SFP+ port combination
- Optional power supply with supplied 5V, 3A USB-C adapter
Technical data:
| Mechanical | |
|---|---|
| Dimensions | 212.9 x 76 x 33.5 mm (8.4 x 3 x 1.3 inches) |
| Weight | 420 g (14.8 oz) |
| Favourite material | Polycarbonate |
| Mounting | Wall mounting possible (kit included in scope of delivery) DIN rail mounting possible (available separately) |
| Hardware | |
| Management interface | Ethernet in-band |
| Network interface | (8) 2.5/1 GbE RJ45 ports (1) 10G SFP+ or 10/5/2.5/1 GbE combo port* If only one is active, GbE can be supplied with power and SFP+ can be used for data |
| Total non-blocking throughput | 30 Gbit/s |
| Switching performance | 60 Gbit/s |
| Forwarding tariff | 44.64 Mpps |
| Performance method | (1) Power supply unit, 5 V DC, 3 A (1) PoE+ (pairA 1, 2+; 3, 6-)(pairB 4, 5+; 7, 8-) |
| Power supply | External AC/DC adapter UniFi PoE switch |
| Supported voltage range | AC/DC input: 5 V DC PoE input: 42.5–57 V DC |
| Max. Power consumption | 14W |
| Button | Factory reset |
| Operating ambient temperature | -20 to 45 °C (-4 to 113 °F) |
| Humidity during operation | 10 to 90 % non-condensing |
| Certifications | CE, FCC, IC |
| Switching functions | |
| Layer 2 functions | STP / RSTP with prioritisation and deactivation at port level Storm control Multicast/broadcast rate limiting flow control Jumbo -frames Egress rate limiting Proprietary loop protection Port isolation Port mirroring |
| LEDs | |
| System | Blue/white;: Power supply. Flashing white: Boot up is running. Flashing blue: Firmware update. Solid white: Factory settings; device is waiting for acceptance. Solid blue: Device has been accepted. |
| Ethernet | Link/Activity PoE input |
| SFP+ | Link/Activity |
| Application requirements | |
| UniFi network | Version 9.0.108 and higher |
