Ubiquiti Switch smart managed Layer2 5 Port • 5x GbE • 1x PoE at In • Desktop • Lüfterlos • UniFi • USW-Flex-2.5G-5

Ubiquiti Switch smart managed Layer2 5 Port • 5x GbE • 1x PoE at In • Desktop • Lüfterlos • UniFi • USW-Flex-2.5G-5
Ubiquiti Switch smart managed Layer2 5 Port • 5x GbE • 1x PoE at In • Desktop • Lüfterlos • UniFi • USW-Flex-2.5G-5
Ubiquiti Switch smart managed Layer2 5 Port • 5x GbE • 1x PoE at In • Desktop • Lüfterlos • UniFi • USW-Flex-2.5G-5
Ubiquiti Switch smart managed Layer2 5 Port • 5x GbE • 1x PoE at In • Desktop • Lüfterlos • UniFi • USW-Flex-2.5G-5
Ubiquiti Switch smart managed Layer2 5 Port • 5x GbE • 1x PoE at In • Desktop • Lüfterlos • UniFi • USW-Flex-2.5G-5

Preview: Ubiquiti Switch smart managed Layer2 5 Port • 5x GbE • 1x PoE at In • Desktop • Lüfterlos • UniFi • USW-Flex-2.5G-5 Preview: Ubiquiti Switch smart managed Layer2 5 Port • 5x GbE • 1x PoE at In • Desktop • Lüfterlos • UniFi • USW-Flex-2.5G-5 Preview: Ubiquiti Switch smart managed Layer2 5 Port • 5x GbE • 1x PoE at In • Desktop • Lüfterlos • UniFi • USW-Flex-2.5G-5 Preview: Ubiquiti Switch smart managed Layer2 5 Port • 5x GbE • 1x PoE at In • Desktop • Lüfterlos • UniFi • USW-Flex-2.5G-5 Preview: Ubiquiti Switch smart managed Layer2 5 Port • 5x GbE • 1x PoE at In • Desktop • Lüfterlos • UniFi • USW-Flex-2.5G-5
product pictures similar, may differ from the product description!

net price plus shipping costs

This product is not available at the moment. Delivery time upon request.

Call us Mail us
Description
Description
Compact 5-port 2.5G switch that can be supplied with power via PoE or a USB-C adapter. (4)... more
Close menu
Product information "Ubiquiti Switch smart managed Layer2 5 Port • 5x GbE • 1x PoE at In • Desktop • Lüfterlos • UniFi • USW-Flex-2.5G-5"
Compact 5-port 2.5G switch that can be supplied with power via PoE or a USB-C adapter.

(4) 2.5 GbE ports

(1) 2.5 GbE PoE input port for the power supply

Optional power supply via the supplied 5V, 1A USB-C adapter

Note: The EU version is only supplied with an EU power plug.

TECHNICAL DATA:

Mechanical
Dimensions 117.1 x 90 x 21.2 mm (4.6 x 3.5 x 0.8 inches)
Weight 206 g (7.3 oz)
Favourite material Polycarbonate
Hardware
Management interface Ethernet in-band
Network interface (5) 1/2.5 GbE RJ45 ports
Total non-blocking throughput 12.5 Gbit/s
Switching performance 25 Gbit/s
Forwarding tariff 18.6 Mpps
Performance method (1) Power supply unit, 5 V DC, 1 A
(1) PoE (pairA 1, 2+; 3, 6-)(pairB 4, 5+; 7, 8-)
Power supply External AC/DC adapter
UniFi PoE switch
Supported voltage range AC/DC input: 5 V DC
PoE input: 44–57 V DC
Max. Power consumption AC/DC input: 5 W
PoE input: 6.4 W
Button Factory reset
Operating ambient temperature -20 to 45 °C (-4 to 113 °F)
Humidity during operation 10 to 90 % non-condensing
Certifications CE, FCC, IC
Switching functions
Layer 2 functions STP / RSTP with prioritisation and deactivation at port level
Port isolation
Storm control
Port mirroring
Multicast/broadcast rate limiting
Flow control
Jumbo frames
Egress rate limiting
Layer 3 functions –
LEDs
System (1) Blue/white;: power supply white;
Flashing: Boot process is running
Flashing blue: Firmware update
Solid white: Factory settings; device is waiting for acceptance
Solid blue: Device has been accepted
Ethernet (5) Grün: Link/Activity
Application requirements
UniFi network Version 8.4.62 and higher
