Ubiquiti UniFi PowerAmp • speaker amplifier • 1x RCA out • 2x RCA in • 1x HDMI • white • UPL-Amp-W

Ubiquiti UniFi PowerAmp • speaker amplifier • 1x RCA out • 2x RCA in • 1x HDMI • white • UPL-Amp-W
product pictures similar, may differ from the product description!

net price plus shipping costs

Expected to be available from 1 January 2025

Call us Mail us
Description
Description
High-quality speaker amplifier for Hi-Fi multi-zone audio streaming and impressive spatial sound... more
Close menu
Product information "Ubiquiti UniFi PowerAmp • speaker amplifier • 1x RCA out • 2x RCA in • 1x HDMI • white • UPL-Amp-W"

High-quality speaker amplifier for Hi-Fi multi-zone audio streaming and impressive spatial sound experiences.

Low latency wireless audio streaming with Apple AirPlay 2 and Spotify Connect

130 watts per channel into 8 ohms

(2) speaker connection outputs with (2) specially designed banana plugs included

(1) Analogue RCA subwoofer output

(2) RCA analogue inputs for left and right channel

(1) HDMI eARC input with impressive surround sound thanks to Dolby Atmos

1.43" rotary knob with touchscreen

Less setup, management and group control with the UniFi Play mobile app

Technical specification

Mechanical
Dimensions With button: 217 x 236.8 x 63.7 mm (8.5 x 9.3 x 2.5 inches)
Without button: 217 x 217 x 63.7 mm (8.5 x 8.5 x 2.5 inches)
Weight 2.4 kg
Handling material Plastic
Mounting Desktop
Colour Black
White
Hardware
Network interface (2) GbE RJ45 ports
WLAN standards 802.11 a/b/g/n/ac
Connectivity WLAN 2.4 G, bandwidth 20/40 MHz
WLAN 5G, bandwidth 20/40/80 MHz
Power method (1) Universal AC input, 100240 V AC, 2.5 A max., 50/60 Hz
Power consumption 17W
LEDs LED ring
LCM display 1.43" rotary knob with touchscreen
Button Factory reset
Operating ambient temperature -5 to 40 °C (23 to 104 °F)
Humidity during operation 5 to 90 % non-condensing
Certifications FCC, IC, CE
Audio
Power per channel (continuous power) 130 W, 8 O, 1 kHz, < 0.05 % THD+N, EIA (CEA-490-A)
260 W, 4 O, 1 kHz, < 0.09 % THD+N, EIA (CEA-490-A)
Amplifier class Class D
Output Stereo sound
Surround format Dolby Atmos, Dolby TrueHD, Dolby Atmos (True HD), Dolby Atmos (Dolby Digital Plus), Dolby Digital, Dolby Digital Plus, Stereo PCM, Multichannel PCM, Dolby Multichannel PCM
Grouping Up to 32 PowerAmps
Audio input (1) HDMI eARC input
(2) RCA analogue input L/R
Audio output (1) Analogue RCA subwoofer output
(2) Speaker connection outputs with (2) banana plugs
Streaming AirPlay2, Spotify Connect, Soundtrack Your Brand*
*Available from 8 November.
Application requirements
UniFi playback UniFi Play iOS and Android: version 1.0.0 and higher
