Ubiquiti Dual Omni antenna AirMax MIMO 2, 4GHz, 10dBi, rocket
product pictures similar, may differ from the product description!
net price plus shipping costs
This product is not available at the moment. Delivery time upon request.
- stock: 0
- part no.: 107399
- vendor: Ubiquiti
- mnufacturer no.: AMO-2G10
- EAN No.: 810354020957
- weight: 3.9kg
- warranty: 12 months
- Do you have any questions concerning this product?
Downloads
data sheet DE
EU RoHS und REACH Erklärung
2.4 GHz, 10 dBi carrier-class 2x2 dual-polarity MIMO omnidirectional antenna.
2x2... more
Product information "Ubiquiti Dual Omni antenna AirMax MIMO 2, 4GHz, 10dBi, rocket"
2.4 GHz, 10 dBi carrier-class 2x2 dual-polarity MIMO omnidirectional antenna.
2x2 dual-polarity MIMO
360° coverage
Easy to assemble
Compatible with RocketPrism
Technical Specifications
| AMO-2G10 | |
|---|---|
| Dimensions | 1030 x 122 x 84 mm (40.6 x 4.8 x 3.3") |
| Weight | 2.1 kg (4.6 lb) |
| Frequency Range | 2.35 - 2.55 GHz |
| Gain | 2.35 - 2.55 GHz |
| Elevation Beamwidth | 12° |
| Max. VSWR | 1.7:1 |
| Downtilt | 4° |
| Wind Survivability | 200 km/h (125 mph) |
| Wind Loading | 62.3 N @ 160 km/h (14 lbf @ 100 mph) |
| Polarization | Dual-Linear |
| Cross-pol Isolation | 25 dB min. |
| ETSI Specification | EN 302 326 DN2 |
| Mounting | Universal Pole Mount, RocketM Bracket, and Weatherproof RF Jumpers Included |
